Additional Features:

• 1 GHz Probe Bandwidth
• <4 pF Input Capacitance
• 10X Attenuation
• 300 V CAT ll Input Voltage
• Designed for use with the MSO/DPO4000B and MSO/DPO5000 Series Oscilloscopes
• Compact Probe Head for Probing Small-geometry Circuit Elements
• Small Probe Body for Enhanced Visibility to the Device-Under-Test
• Rigid Tip for Secure Device-Under-Test Connectivity
• Replaceable Probe Tip Cartridges
• Large Accessory Set for Versatile Connectivity
• Integrated Oscilloscope and Probe Measurement System provides Intelligent Communication that Automatically Scales and Adjusts Units on the Oscilloscope Display to Match the Probe Attenuation
• Built-in AC Compensation Optimizes Signal Path across the Entire Frequency Range

Standard Accessories:

• Rigid tip 3.8 mm
• Flex ground spring SHORT 3.8 mm
• Long ground spring
• Alligator ground (6 in.)
• Hook tip (regular)
• Hook tip (micro)
• IC cap (universal) 3.8 mm

Applications:

• Low-power Devices
• Service
• Manufacturing Engineering Test
• Research and Development

The extremely low capacitive loading limits adverse affects on your circuits and is more forgiving of longer ground leads. And with the probe's wide bandwidth, you can see the high-frequency components in your signal which is critical for high-speed applications. The TPP1000 passive voltage probe offers all the benefits of general-purpose probes like high dynamic range, flexible connection options, and robust mechanical design, while providing the performance of active probes.
